Severe Service Valves: Everything You Need To Know

Severe service valves play an important role in industrial processes that require precise control under extreme conditions. Industries like oil and gas, power generation, and chemical processing often operate under intense pressures, extreme temperatures, and exposure to corrosive or abrasive substances. Unlike standard control valves, severe service valves are engineered to withstand these harsh conditions while maintaining high performance and reliability.

In this article, we’ll explore the challenges of severe service applications, the innovative techniques and manufacturing that improve valve durability, and how customization can optimize valve performance for specific processes.

What are Severe Service Valves?

Severe service valves are specialized control valves designed to handle the most demanding industrial conditions. These valves operate in environments that expose them to extreme pressures, high temperatures, and harsh chemicals or abrasive materials that can quickly degrade standard valves.

From our own experience, we know that 15% of control valves cause 85% of valve-related issues in industrial plants. These ‘problem valves’ can often result from using standard designs in severe service applications that fail to meet the process's demands. Failures can lead to cavitation, flashing, noise, corrosion, and erosion, resulting in costly downtime, reduced efficiency, and safety risks. Severe service valves address these challenges through advanced materials, specialized trims, and specific designs that ensure long-lasting performance.

Challenges in Severe Service Applications

Severe service environments create unique challenges that can compromise valve performance and longevity. Understanding these challenges is essential for designing and specifying effective solutions.

Cavitation

Cavitation occurs when rapid pressure drops cause vapor bubbles to form and collapse violently, eroding valve surfaces. This phenomenon is common in high-velocity flows and can significantly shorten a valve’s lifespan. For example, cavitation damage creates pitting on the metal surface, leading to structural weakness and eventual failure.

Flashing

Flashing happens when a fluid changes phase—typically from liquid to gas—as it moves through the valve. Unlike cavitation, the vapor bubbles formed during flashing do not collapse but carry abrasive particles downstream. These particles erode valve trims, seats, and even downstream piping, causing extensive damage.

Noise

Noise occurs when turbulence and high velocities create vibration within the valve. This impacts worker safety by exceeding acceptable decibel levels and accelerating wear and tear on valve components, potentially leading to premature failure. Noise control in severe service valves ensures operational safety and system efficiency.

Corrosion and Erosion

Valves often encounter corrosive chemicals and abrasive substances that wear away their surfaces. Corrosion can result from chemical reactions, while erosion stems from particles in the media scraping against the valve. These factors reduce the reliability and longevity of standard valves in severe service.

For an in-depth look at predicting and mitigating cavitation, read Understanding and Predicting Cavitation in Control Valves.

Key Design Features of Severe Service Valves

Innovative design elements give severe service valves the durability and performance they need to overcome these challenges. They include:

Specialized Trims

Specialized trims are essential to severe service valves, as they regulate fluid flow and address key challenges like cavitation, noise, and erosion. By customizing trim designs to the application, severe service valves achieve precise control, enhanced durability, and extended operational life.

• The ST-2 multi-stage trim reduces pressure gradually across multiple stages, effectively preventing cavitation and minimizing hydrodynamic noise. This makes it ideal for high-pressure drop applications, where rapid fluid velocity changes can damage the valve or downstream piping.
• The ST-3 noise abatement trim is designed to reduce noise levels by up to 30 dBA in high-velocity gas applications. It also mitigates turbulence, protecting the valve and ensuring consistent performance.

Severe service trims like these provide the advanced control needed to handle the extreme conditions common in severe service applications. These trims, paired with durable materials and valve seats, which we will cover next, help protect valves from wear and tear, ensuring reliable operation and minimizing maintenance demands.

Durable Valve Seats

Valve seats play a crucial role in maintaining a tight shutoff while resisting erosion from abrasive media. The ST-5 Venturi seat redirects erosive forces away from critical components, ensuring a longer operational lifespan.

Advanced Materials and Processes

Materials like Hastelloy, Monel, and Titanium provide superior resistance to corrosion and erosion. Additionally, the CVD-5B hardening process infuses boron into metal surfaces, creating a wear-resistant layer that withstands temperatures up to 1200°F.

Learn more about how we design SSVs: 5 Crucial Design Elements in Severe Service Control Valves

Why Customization Matters for Severe Service Valves

Every severe service application presents unique challenges, making customization extremely important for long-term successful use. Custom severe service valves address:

• Precise flow control: Trims are designed to optimize performance according to specific application requirements.
• Durability: Advanced materials and trims are designed to handle more extreme conditions.
• Reduced downtime: Designs specified for severe service applications lower the risk of failure.

Explore the value of customization in Why It Pays to Use a Custom Severe Service Valve.

Specifying Control Valves for Your Applications

Specifying the right control valve for severe service applications ensures optimal performance, durability, and reliability under extreme conditions. To achieve this, several factors must be considered during the specification process:

Material Selection

Selecting the appropriate materials is vital for valves operating in harsh environments. Materials must resist corrosion, erosion, and high temperatures. Options we’ve explored above like Hastelloy and Monel provide exceptional resistance to corrosive substances, while titanium handles extreme pressures and temperatures.

Trim and Flow Control

Effective flow management minimizes challenges like cavitation, flashing, and noise. Multi-stage trims such as the ST-2 gradually reduce pressure to prevent cavitation, while noise-abatement trims like the ST-3 reduce turbulence and cut noise by up to 30 dBA. For less severe conditions, single-stage trims such as the ST-1 offer a cost-effective solution by directing cavitation bubbles toward the cage center to protect valve surfaces.

Valve Seat and Seal Design

Achieving a tight shutoff is extremely important for severe service applications. Valve seats like the ST-5 Venturi seat redirect erosive forces to replaceable sections, protecting critical components. Combining this with actuator solutions, such as the OpTK piston actuator, ensures precise control and long-term reliability.

Utilizing Specification Software

Trimteck’s AccuValve™ simplifies the valve selection process by analyzing fluid properties, operating pressures, and flow rates. This data-driven approach recommends the optimal materials, trims, and valve configurations for your application, ensuring compatibility with severe service environments.

For more information on this, read our dedicated article on Specifying Control Valves for Severe Service Applications.

Getting Severe Service Valves Right

Severe service valves deliver reliability, safety, and efficiency in demanding industrial processes that will allow for no other options. Advanced materials, innovative trims, and custom solutions ensure their success under extreme conditions. Contact Trimteck for expert guidance, or use AccuValve™ to simplify valve selection.
